- Waterproof, conforms to IP68
- Strong Zinc Alloy Electroplated anti-vandal case
- Capacity: 10,000 cards/codes
- Multiple accesses, card/ code/ Tuya APP
- Can be used as a stand alone keypad
- Backlight keys
- Wiegand 26 input for connection to external reader
- Wiegand 26 output for connection to a controller
- Adjustable Door Output time
- Very low power consumption (30mA)
- With data backup function
- Can set relay toggle mode, pure reader mode(WG26/34/37/58 output), standalone access control mode
- Easy to install and program
- Built in buzzer
- Red, Yellow and Green LEDS display the working status
Specs.:
Operating Voltage | DC 12V±10% |
User Capacity | 2000 |
Card Reading Distance | 3-6 cm |
Active Current | ＜60mA |
Idle Current | 25±5 mA |
Lock Output Load | Max 3A |
Alarm Output Load | Max 20A |
Operating Temperature | -45℃～60℃ |
Operating Humidity | 10%- 90% RH |
Waterproof | Conforms to IP68 |
Adjustable Door Relay time | 0 -99 seconds |
Adjustable Alarm Time | 0- 3 minutes |
Wiegand Interface | Wiegand 26 bit |
Wiring Connections | Electric Lock, Exit Button, External Alarm,External reader |
| Credential Type | 125kHz |
| IP standard | IP68 |
